The IR-842A(LED)-WP is a stainless steel infrared sensor exit button, with dimensions of 76mm in length, 91mm in width, and 46mm in height. It meets American standards and is suitable for a variety of lock types. The induction distance is adjustable, reaching up to 10cm, and the time delay can be configured to 3 seconds. The red LED indicator signifies that the power is on (standby), while the green LED indicator shows that the device is in use (sensation).
Product parameter Parameter Description
Feature Mortise mount
Dimensions 76Lx91Wx46H(mm)
Input DC12 ~ 24
Current ≤70mA
Contact Rating 1A@30VDC
Output contact NO/ NC/ COM
Mechanical life 100,00 tested
Suitable for Door Hollow Door
Structure Zinc alloy material
Surface Treatment Zinc alloy with black paint treatment
Operating Temp -20°C ~ +55°C (14 – 131F)
Suitable humidity 0 – 95% (relative humidity)
Detection Range 10cm (±20%)
Time delay 3S
LED Indicator Red LED indicator: Power ON (standby); Green LED indicator: Power ON (sensation)
Waterproof Level IP67
Weight 0.5kg
Certification CE-EMC CE-LVD FCC RoHs REACH WEEE
